Item Details:
1. Material: Aluminum alloy;
2. Process: CNC integrated carving;
3. Charging interface: Android USB cable interface;
4. Battery capacity: 1800mA;
5. Charging time: Fast charging, it can be fully charged in 1.5-2 hours without electricity;
6. Use time: The output current is 2.0A, under normal 8V voltage, it can work continuously for more than 7 hours, the voltage is stable, and it can be used for about 8 hours for intermittent use;
7. LCD display content: Working time count (hour-minute count) + two-digit output voltage + battery capacity;
8. Motor: Imported hollow cup motor (9V 12000 rpm);
9. Stroke: 0-0.35mm;
10. Starting voltage: With memory function, the starting voltage is the value of the last shutdown voltage;
11. Working voltage range: 5-12V.
Instructions for use:
The device is a tattoo pen with a built-in lithium battery, which can be used directly without foot pedals and hook lines. It is composed of two parts: (1). upper half lithium battery power supply; (2). lower half tattoo pen; the middle part can be unscrewed to replace the upper half lithium battery, the specific functions are as follows:
1. Power on: Long press the middle “O” button for 5 seconds to turn on, and then long press for 5 seconds to turn off;
2. Pause: Short press the “O” key during normal work to pause the work, and then press again to resume working status;
3. Adjust the voltage: adjust the voltage level by pressing the “+” or “-” key, each press to adjust 0.5V, the minimum voltage: 5V, the maximum voltage 12V;
4. Battery display: It is displayed on the LCD screen, it is full of 4 grids, and it needs to be charged when the last power is left;
5. Daily charging: external charging port, you can use the Android USB cable to charge;
